LTE Router

3G / 4G service provider use different standards and frequency for their data service. You need to check which router type is working with your provider.  Only the internal modem of the router is different, WLAN, ethernet ports.. are the same.

Product codemain use of routerFrequency
800-099106
Option LTE Router
Europe,
Middle East,
Africa,
Korea,
Thailand
4G FDD-LTE: B1 (2100 MHz),B3 (1800MHz), B7 (2600MHz), B8 (900MHz), B20 (800 MHz), B28 (700 MHz)

3G: B1 (2100 MHz), B8 (900 MHz)

GSM/EDGE: 900/1800 MHz
800-099107
Option LTE Router NA
North America
(AT&T, Bell, T-Mobile)
4G FDD-LTE: B2(1900 MHz), B4 (1700 MHz), B12 (700 MHz9

3G: B2 (1900 MHz), B4 (1700 MHz), B5 (850 MHz)
800-099108
Option LTE Router NV
North America
(Verizon)
4G FDD-LTE: B4 (1700 MHz), B13 (700 MHz)
800-099109
Option LTE Router A
Australia (Telstra)4G FDD-LTE: B1 (2100 MHz), B3 (1800 MHz), B5 (850 MHz), B7 (2600 MHz), B28 (700 MHz)

3G: B1 (2100 MHz), B5 (850 MHz)
800-099110
Option LTE Router S
South America,
Australia,
New Zealand,
Taiwan
4G FDD-LTE: B1(2100 MHz), B2 (1900 MHz), B3 (1800 MHz), B4 (1700 MHz), B5 (850 MHz), B7 (2600 MHz), B8 (900 MHz), B28 (700 MHz)

4G TDD-LTE: B40 (2300 MHz)

3G: B1 (2100 MHz), B2 (1900 MHz), B5 (850 MHz), B8 (900 MHz)

GSM/EDGE: 850/900/1800/1900 MHz
800-099111
Option LTE Router J
Japan4G FDD-LTE: B1 (2100 MHz), B3 (1800 MHz), B8 (900 MHz), B18 (850 MHz), B19 (850 MHz), B26 (850 MHz)

4G TDD-LTE: B41 (2500 MHz)

3G: B1 (2100 MHz), B6 (850 MHz), B8 (900 MHz), B19 (800MHz)
800-099112
Option LTE Router V
Global4G FDD-LTE: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28

4G TDD-LTE: B38, B39, B40, B41

3G: B1, B2, B4,B5, B6, B8, B19

2G: B2, B3, B5, B8
800-099113
Option LTE Router H

Middle East,
Africa,
Korea,
Thailand,
India
4G FDD-LTE: B1 (2100 MHz),B3 (1800MHz), B5 (850MHz), B7 (2600MHz), B8 (900MHz), B20 (800 MHz)

4G TDD-LTE: B38, B40, B41

3G: B1 (2100 MHz), B5 ( 850 MHz), B8 (900 MHz)

GSM/EDGE: B3 (900 MHz), B8 (1800 MHz)
